Listing details

2027 Horizon Trailers EWZ 40'GN Triple Axle Drive Over Trailer

Brand: Horizon Trailers. Type: Equipment Trailer. Length: 40' 0". Width: 8' 6". GVWR: 22,400 lb. Hitch: Gooseneck. Color: Black. Stock number: 21077. Location: Cave City, KY. TRAILER SPECS LENGTH: 40’ DECK WIDTH: 102” DECK HEIGHT: 30” WEIGHT RATING GAWR: 7,000 LBS FINISH PAINT TYPE: POWDERCOAT PREP: STEEL GRIT BLASTED WARRANTY AXLE WARRANTY: 5 YEAR SPRING AXLE WARRANTY TRAILER WARRANTY: 3 YEAR FRAME / 1 YEAR PARTS WARRANTY TONGUE TOUNGE TYPE: 10" ENGINEERED I-BEAM LENGTH: 98" (FROM BEHIND RISER) HEIGHT: 70" (FROM UNDERNEATH NECK] SPARE: WELD ON SPARE TIRE MOUNT STORAGE BEHIND NECK: STORAGE BOX / WINCH READY COUPLER STANDARD COUPLER: ADJUSTABLE 2-5/16" GN COUPLER [30,000 LBS] JACKS FRONT JACKS: 2 SIDE WIND SPRING-LOADED DROP JACK LEGS (12,000 LBS) TOOLBOX: MEGA LOCKABLE TOOLBOX SAFETY SAFETY CHAINS: 3/8" GRADE 70 SAFETY CHAIN W/CLEVIS HOOK [2 EACH] CHASSIS FRAME MAIN FRAME: 10" I-BEAM [15 LBS/FT] W/ 4" X 4" ANGLE IRON BRIDGE TORQUE TUBE30' AND UP ONLY: 4,1/2" TUBE DECK BED REAR OF DECK: 4' DOVETAIL DECK FRAME: 3/16" DIAMOND PLATE FLOORING: PINE LUMBER FLOOR CROSSMEMBERS: 3" CHANNEL (3.50 LBS/FT] 16" SPACING DECK HEIGHT: 30” DECK WIDTH: 102” WIDTH BETWEEN FENDERS: 83” D-RINGS: 2 D-RINGS IN BETWEEN FENDERS BOLT ON SWIVEL D- RINGS TIE DOWN SLOTS: 2- FLUSH MOUNT GALVANIZED SWIVEL D-RINGS FRONT OF TRAILER SLOTS FOR LATCH ON TIE DOWN FITTINGS ALONG SIDES OF DECK SIDES RUB RAIL: 2" X 3/8" RUB RAIL STAKE POCKETS: 1,5/8" X 3,5/8" (ID] STAKE POCKETS (SPACED AT 24"] SPOOLS: 2" X 10GA. PIPE SPOOLS (SPACED AT 24"] FENDERS: 3/16" DIAMOND PLATE DRIVE OVER FENDERS REAR RAMPS: RAMP POCKETS W/ 5' 6" LONG HEAVY-DUTY SLIDE IN 4" CHANNEL RAMPS RUNNING GEAR TIRES TYPE: RADIAL TIRES SIZE: ST235/85R16 PLY: 10 RATING: 3,520 LBS RIMS: 16" BLACK MOD WHEELS SUSPENSION AXLE TYPE: 7K ELECTRIC BRAKE AUTO ADJUST EZ LUBE SPRING AXLES BOLT PATTERN: 8 ON 6.5" AXLE COUNT: 3 SUSPENSION TYPE: SPRING AXLE WARRANTY: 5 YEAR SPRING AXLE WARRANTY ELECTRICAL AND LIGHTING BATTERY AND CHARGING BREAKAWAY SYSTEM: 2382 BRIGHTWAY GROUP ELECTRIC BREAKAWAY KIT WIRING HARNESS: ALL-WEATHER WIRING HARNESS (7-WAY RV] FRAME WIRING: DOUBLE INSULATED WIRING HARNESS LIGHTING LIGHTS: DOT APPROVED TECNIQ LED LIGHTS SAFETY REFLECTIVE TAPE: 3M DOT COMPLIANT REFLECTIVE TAPE
